Anran CCTV Products General FAQ
How to Match Code the Wireless Camera that have network port to NVR?
If your camera has a network port, please follow the steps below to match code the camera.
Please refer to below picture to connect the camera to the NVR.
Install antennas for cameras and take it close to the NVR; Then plug the camera to power adapter and use a network cable to connect the camera to NVR’s LAN port.
Before match code please delete the corresponding channel to spare a channel out for a new camera, then you can match and add new camera into the channel.
Match code the camera, you need to put the camera next to the NVR
1) Please attached a camera to the NVR (use a net cable) and the camera needs to be connected to the power supply
2) Right clicked to “Video manage”
3) “Refreshed” to allow the NVR to find the attached camera (The camera’s IP on the above box must be 192.168.x.x)
4) Found a blank line in the lower section
5) Clicked on “Match Code”
6) Wait for about 30s and the camera connect success (camera’s IP 172.20.14.x)
Load More : ADVR FAQ Problem class
How to set up wireless camera system Email alarm?
Please click here learm more about setting email alarm: email alarm
There are several requirements of hard disk drive (HDD)
1. The disk had better be the one used for survilliance, not for computer use.
2. The type should be SATA. SATA2(3GB/s) or SATA3（6GB/s）is recommened. If you connect a USB stick or drive to USB port of DVR, DVR can back up video from internal hard disk drive to USB stick, but can’t record to USB stick directly.
3. We recommend 5400 RPM.
4. size is 3.5” .
5. The capacity should be less than or equal to recorder’s maximum capacity.
Note: Before installing the hard drive disk, please power off the system if it is on.
Step1. Loose the two screws which are fixing the box cover.
Step2. Push forward the cover to the end and remove it.
Step3. Connect the hard drive to the nVR System
Step4. Turn on the NVR and check if it detects the hard drive.System setup—>General setup—>HDD setup,
Then, click format and format HDD,Final,power off the system.
Step5. Fix the hard drive inside the box.
Step6. Put the cover back to position and install the screws.
Viewing Wireless Camera System on Computer by IE
You can view camera on computer or Laptop by IE in locate or remotely.
Step1. Open IE browser on your computer or Laptop, go to “www.dvr163.com”. (If you don’t have IE browser, please download it first)
Step2. Choose English first, Click User name login→ Input your username and password →click login. If this was the first time that you use it, please click “New account” to apply an account.
Tips: If you have an account on your phone APP, then you can use the same account to login.
Step3. Input the following information and click “Add’’ to add the camera systems.
Cloud ID: Please input your Cloud ID (find it in the NVR’s Network Setting, or right bottom corner of the screen).
Device set name: Name it yourself.
Device user name: This is NVR system’s default user name, if you hadn’t changed it, it should be admin.
Device password: This is NVR system’s default password, if you hadn’t changed it, it should be blank. If you have modified the password, please enter the password which you had set.
Tips: If your APP account has already added the camera system, please ignore the step3 and you can follow step4 directly.
Step4. Click Live Online and Click install Update Controls. When you install the plug-in file, please choose the English language.
Step5. When you have finished installing the plug-in, please click Camera list, then you can view your video now.
No Video Output on the Monitor/TV from Wireless Camera System
If there’s no video output on the monitor from camera system, there are several possible causes for the problem, you can refer to the following solution:
1. The video output resolution of the camera system is not supported with the monitor/TV
*Please use your TV remote control to switch signal source. If the signal source is right but still can’t get camera screen, this is typically caused by resolution compatibility issue.
*The NVR default resolution is 1280×1024. If monitor can’t show any image of cameras, it can prove the display resolution of NVR is higher than your monitor’s, please adjust the resolution of your monitor to 1280×1024 or use a higher than 1280×1024 resolution monitor to connect NVR. (The monitor’s resolution must be higher than the display resolution of NVR. If not, monitor is not able to show any image of cameras).
2. The monitor/TV or VGA/HDMI cable is defective or damaged
*Please use another HDMI/VGA cable connect camera system with TV/monitor (shorter than 15 m).
*Please use another TV/monitor connect camera system and try again.
3. Camera system cannot be turned on
*Please change the power supply or outlet (12V-2A or 3A is for NVR, and 12V-1A is for camera), use another working power supply and check whether it works normally or not. If the power supply is damaged, the power will be insufficient, resulting in the system unable to run and no video.
*Don’t connect camera system to wifi router and then check whether it working or not.
*Remove the hard disk (also don’t connect NVR to wifi router, only connect a monitor), and then restart NVR, check whether it working or not.
Learn More:
Please go to your monitor, and press and hold the left mouse button for 15 seconds and then release it. After two minutes, the recorder will restart. Restore to default resolution
What should I do if I forget Wireless Camera System password?
Our Wireless Camera System’s NVR default user name is admin, and default password is no password (means you do not have to input anything).
1. If you forgot the new password created by yourself or the default password could’t work, please follow below video link to change password to default.
VIDEO
2.If method 1 doesn’t work, please tell me the time in the lower left corner of your camera system on monitor (send a picture is best), and then we will send you a super password. Please send email to this emailbox: support@anran-cctv.com
How to upgrade the Wireless Camera System?
Please send your camera system version info to our support team, and then they will send you the latest upgrade firmware.
support emailbox: support@anran-cctv.com
How to Match Code the Wireless Camera to connect with NVR?
1. Please put the camera next to the NVR, and connected the camera to the power supply
2. Please go to “Video Manage” and delete the “IP disconnected” camera from below.
3. Press the camera’s reset button for 13-15 seconds (the button next to the camera’s power cord) and then wait about 1 minutes. The camera automatically restarts.
4. Right click–and then click “Wifi add” to Match Code the camera
5. Press the reset button 3s again, it will automatically search and add cameras
6. A few seconds later the picture will be shown on the screen
7. Click “Exit” after all cameras are connected
Wireless Camera shows “IPC disconnected”, “No video source”, “Connection failed”
*Please make sure the wireless camera and NVR are within the valid signal range. Do not install the camera too far from the NVR, otherwise the camera will “Connection failed” or “IPC disconnected” .
*Checking the power adapter and antenna, use another working power adapter and antenna for this camera and check whether it will work normally or not.
*Use your finger cover the camera sensor or place the camera in a dark environment to check whether the Infrared lights will turn on or whether you can hear a click sound. If not, please restore the camera to factory settings and try again.
*Match Code the camera again CLICK HERE
View Wireless Camera System on Computer Software “EseeCloud”
“EseeCloud” can help you to manage your NVR remotely. But before adding your NVR to “EseeCloud”, please make sure you have connected your NVR to the Internet successfully.
Detailed steps and video teaching. Click Here
View Wireless Camera System on phone APP
Step1. Download the APP and install it on your phone.
—-Please search “ARCCTV” in Google play or Apple store and install it on your phone.
Step2. Run the “ARCCTV” APP and register an account (for first time using) and then login.
Step3. Click the “+”, then click “Kit”—“add manually”
Step4. Add camera system-Learn More
Cloud ID: you can find it in the NVR “Network Setup”
User Name: default user name is “admin”
Password: Default password is nothing. no password.
Tips: If you have already set the password for your NVR, please input it. Remember it is the camera system password, not the APP login password
Step5. On your device list, click it to view the cameras.
Playback video on APP
How to Set Motion Detection for Wireless Camera System?
Motion Record. Motion Record means to record only when movement is detected.
1. Right click→System Setup→Record Setup→Record Plan. By unselecting “Time” and selecting “Motion”, the channel will record only when motion detected (Click “Reset” and you can reset the default settings. Long press the left mouse button in the box and drag it, you can quickly set up the recording plan).
2. Go to NVR system, right click the mouse: System setup→Channel Setup→Video detection. Check Enable for Motion Detection
Channel: which camera you want to set Motion Record
Detection: choose “Motion” and need ticked “Enable”
Sensitivity: Sensitivity adjustment
Alarm duration: The length of the alarm recording
Arming time—click this button, which you can set the alarm time.
Area edit— click this button, which you can modify the motion detection area. (default motion detection area is all the image which camera can see)
System Initializing issue on Wireless Camera System
Stopped on the logo interface after rebooting and there was no response at all.
1. Please change the power supply (12V-2A/3A is for NVR, and 12V-1A is for camera), use another working power supply and check whether it working or not. If the power is defective, the power will be insufficient, resulting in the system unable to run.
2. Please don’t connect your camera system to your WiFi router and then check whether it working or not.
3. Please remove the hard disk (also don’t connect NVR to WiFi router, only connect a monitor), and then restart NVR, check whether it working or not.
If your camera system working again, please upgrade your camera system in time.
Why does wireless camera system send so many email or APP false alert?
To explain this question, we need know the theory how motion detection works.
The NVR system can detect small image optical change. It can be triggered by small image change from camera. Image is transmitted by light signal.
Therefore, even if there is no object in front of camera such as human, animal or car, system may still be triggered by small light change such as floating cloud, shaking leaf.
Most customers hope the system can only be triggered by big object like people and ignore small movement. But based on the theory how motion detection works, there are false alarm.
It is hard to say the system is faulty since not only ANRAN brand system faces such issue, but also other brands who use light sensor to work for motion detection function.
How to reduce email and APP false alert?
1. To reduce false alarm, you can turn the sensibility to lower and set the alarm area. (The alarm area defaults to all areas have been selected.)
2. Click “Arming Time”, you can set the notifications time of email alert and APP alert.
3. Please upgrade your camera (you can upgrade it from the network server)
MY NVR 12 inch System didnt come with hard drive. How can i connect hard drive to the system. Do i open the 12inch NVR system and connect the hard drive or i can use USB port on the 12 inch NVR to connect normal computer external hard drive.
Below 12 inch NVR information
Device Name: W-NVR
Device model: KS208-3WS
Device Serial No. N6024609034347
Hardware ID: 9021160200
