D-Link Ip Camera Full Guide

    1. How do I install my DCS-8xxxLH-series camera?
    1. A:
    2. Note This FAQ is based on the mydlink app version 1.5.4 (build 109) from Android (v8.0.0). The iOS version may look a little different.

      To setup your camera with the mydlink app, follow the steps below:



      Step 1: Launch the mydlink app. Log in with your mydlink account username and password. This will be the same username and password if you have used the mydlink Lite or mydlink Home app. If you have never created a mydlink account, you can create one.



      Step 2: Tap the settings icon (3 lines in the upper left corner).



      home settings button



      Step 3: Select Add a Device.



      home settings menu addadevice



      Step 4: Tap Yes to scan the QR code.The QR code is located on the label on the bottom of the camera or on the Wi-Fi configuration card included with the product. If the label or card are missing, tap No and select from the drop-down list.



      uap add 03



      Step 5: If you tapped Yes, scan the QR code. If you are having trouble scanning the QR code, move to a brighter lit area. If you tapped No, select the camera model from the list.



      Step 6: Tap Next. Please wait about a minute (or less).



      Step 7:  Tap Device Location to select where your camera will be setup. Select from the list or scroll to the bottom and tap Add Location to create your own.



      Setup device profile select location     device locations



      Step 8: Tap Choose Your Wi-Fi Network. Select the WiFi network you want to connect the camera to (note this should be the same network that your mobile device running this app is on). Enter the Wi-Fi password and then tap Next.



      Setup device profile select wifi     Setup device profile select wifi2



      Step 9: If you want this camera to be displayed on the “Home” screen, tap Add to Shortcut (checked by default). Tap Next at the bottom to continue.



      Setup device profile shortcut



      Step 10: The camera will now save your Wi-Fi settings, and then bind to your mydlink account. This process can take up to 3 minutes.



      Note: If you receive an error during the Setup Wi-Fi process, make sure you are entering the Wi-Fi password correctly. Remember it is case-sensitive. Also make sure the camera is within range of your wireless router, and that the router has DHCP enabled and does not have any filtering which may block the camera from connecting.



      If you receive an error during the Binding process, this usually means the camera cannot connect to the mydlink servers. It is best to reboot your router, close the mydlink app, and reset the camera (hold a paperclip in the reset hole for 10 seconds and release. The LED on the back should turn red). Once your router has rebooted, open the mydlink app and set it the camera again. If you continue to get errors, please contact D-Link support at 1-877-453-5465. Support is free and available 24/7.



      Step 11: Once the camera setup is finished, the following message will appear. If you want to add the camera to cloud recording, tap Yes, or tap Later.



      setup successful



      Step 12: If you tapped Yes, a new Automation will be created to record video detected by motion to your cloud recording subscription (free or paid). Tap the check mark at the top right corner to finish setup.





      setup enable recording

    1. How do I set up motion detection using the mydlink app?
    1. A:
    2. Note: This FAQ is for the mydlink app, not mydlink Lite. The screen shots are from the Android version v1.7.1 (build 133). The iOS version may look a little different.

      When you first install your camera, motion detection as well as the automation rule (record and notification) is automatically setup. To enable/edit motion detection, follow the steps below:



      Step 1: Launch the mydlink app.



      Step 2: Tap Devices at the bottom of the home screen or tap the menu in the upper left corner, tap Devices. You can also tap the camera in your shortcuts and tap the live video to access the camera settings (skip to step 5).



      step02   step02 A



      Step 3: Tap Camera.



      step03



      Step 4: Select the camera from the dial and then tap the gear icon



      step04



      Step 5: Tap Motion Setting.



      step05



      Step 6: Tap where you want to detect motion (represented by a orange square). Then select the sensitivity (0-100, 100 being the most sensitive). Once finished, tap (iOS) or tap the back button (Android) to save your settings.



      step06



      Step 7: Your settings will be saved.



      Note: To turn “off” motion detection, tap the Clear All button, and then change the sensitivity to 0. Tap back to save your settings.

    1. How do I view video files from cloud recording in the mydlink app?
    1. A:
    2. Note: Screen shots below are from the Android version of the mydlink app. The iOS version may vary. When asked to “tap back”, in the iOS version tap the < icon in the upper left corner.

      To view videos from the mydlink cloud, follow the steps below:



      Step 1: Launch the mydlink app.



      Step 2: Tap the menu icon in the upper left corner. You can also tap Event & Video at the bottom.



      home settings button



      Step 3: Tap Event & Video.



      home settings menu eventvideo



      Step 4: Tap Event.



      A11192 step04



      Step 5: At the top, select the day you want to view video from. The videos will be listed newest to oldest and will display if detected by motion or sound. Tap the video to watch it.



      A11192 step05 new



      Step 6: You can perform the following on the view video screen:

      • Rotate your device to view full screen
      • Tap the Share icon to send the video via email, text, and other services installed on your device such as YouTube and Instagram
      • Tap the Favorite icon (star) in the upper right to mark the video as a favorite
      • Tap the Camera icon to save an image from the video
      • Tap the play/pause button to pause and play the video
      • Tap the down-arrow icon to save the video to your device



      A11192 step07



      Step 7: Tap back to go back to the list of videos (Timeline). To delete videos, tap Edit in the upper right and then select the videos you want to remove. Tap Remove in the bottom right corner to delete.



      A11192 step 08 new

    1. How do I set up Automation using the mydlink app?
    1. A:
    2. Automation allows you to trigger an entire chain of device actions with customized automations. (e.g., You can set the an automation to Record, and send notifications when motion or sound is detection).

      Note: This Automation example will show you how to setup Recording by Motion.



      Step 1: Launch the mydlink app and sign into your account.



      Step 2: Tap the menu icon on the top left.



      home settings button



      Step 3: Tap Settings.



      home settings menu settings



      Step 4: Tap Automation.



      01 settings automation



      Step 5: Tap the + sign.



      02 automation add



      Step 6: Tap the + sign to add a new rule.



      03 automation addrule



      Step 7: Tap the icon next to the trigger type you want (motion or sound detection), then tap Next. In this example, the DCS-8000LH motion detection is selected.



      Note: You can select multiple events.



      04 automation event



      Step 8: Tap the icon next to the event action you want, then tap Next. In this example, Recording (records video to the cloud) and Push Notification (sends a push notification to the device with the mydlink app) are selected.



      Note: you can select multiple actions.



      05 automation action



      Step 9: Tap Save.



      06 automation save



      Step 10: Tap Go Ahead.



      07 go ahead



      Step 11: Your new automation will appear. Tap on the circle icon under Rule 1 to edit any events and/or actions. Tap the trash can icon in the upper right corner to delete the entire Automation.  You can create multiple rules for each Automation. Click the + in the lower right corner and repeat steps 7-10).



      Next to the automation name, tap the > to rename and select a different icon (shown next to Automation 1 in the example).



      08 automation rule1

    1. How do I enable cloud recording for my camera?
    1. A:
    2. Step 1: Launch the mydlink app and sign into your account.

      Step 2: Tap the menu icon in the upper left corner.



      home settings button



      Step 3: Tap Cloud Recording.



      home settings menu cloudrecording



      Step 4: Tap Subscribe.



      step4



      Step 5: Choose an Available Plan.



      step5



      Step 6: Tap Subscribe Now.



      step6



      Step 7: Tap OK.



      step7



      Step 8: Tap Next.



      step8



      Step 9: Select the camera you want to enable the cloud recording for, then tap on the  check  on the top right.



      step9



      Step 10: Tap the  check on the top right .



      step10



      Step 11Click here to set up recording on your camera.








      To add additional cameras with Cloud Recording follow the steps below:



      Step 1: Tap the menu icon on the top left.



      home settings button



      Step 2: Tap Cloud Recording.



      home settings menu cloudrecording



      Step 3: Tap the gear icon.



      2step3



      Step 4: Select the additional camera(s) you want to enable Cloud Recording for then tap  check



      2step4



      Step 5: Tap Set a Rule.



      2step5b



      Step 6: Tap the settings icon.



      2step6



      Step 7: Tap the + on the bottom right to add a rule for the new camera.



      2step7



      Step 8: Select the event you would like to a add to your automation, then tap Next (This example shows motion detection).



      2step8b



      Step 9: Select the action you would like to add to your automation, then tap Next (This example shows Cloud recording and Push Notifications).



      2step9



      Step 10: Tap check



      2step10



      Step 11: Now you can see the two Rules for the two cameras.



      2step11

    1. How do I view video files from cloud recording in the mydlink app?
    1. A:
    2. Note: Screen shots below are from the Android version of the mydlink app. The iOS version may vary. When asked to “tap back”, in the iOS version tap the < icon in the upper left corner.

      To view videos from the mydlink cloud, follow the steps below:



      Step 1: Launch the mydlink app.



      Step 2: Tap the menu icon in the upper left corner. You can also tap Event & Video at the bottom.



      home settings button



      Step 3: Tap Event & Video.



      home settings menu eventvideo



      Step 4: Tap Event.



      A11192 step04



      Step 5: At the top, select the day you want to view video from. The videos will be listed newest to oldest and will display if detected by motion or sound. Tap the video to watch it.



      A11192 step05 new



      Step 6: You can perform the following on the view video screen:

      • Rotate your device to view full screen
      • Tap the Share icon to send the video via email, text, and other services installed on your device such as YouTube and Instagram
      • Tap the Favorite icon (star) in the upper right to mark the video as a favorite
      • Tap the Camera icon to save an image from the video
      • Tap the play/pause button to pause and play the video
      • Tap the down-arrow icon to save the video to your device



      A11192 step07



      Step 7: Tap back to go back to the list of videos (Timeline). To delete videos, tap Edit in the upper right and then select the videos you want to remove. Tap Remove in the bottom right corner to delete.



      A11192 step 08 new
